The LM78XX series of voltage regulators are commonly used in various electronics appliances and projects. LM7806 IC comes in the family and provides a fixed regulated output of 6V DC for a variable input voltage range of 8 – 25V DC. Features and Specifications This section mentions some of the features and specifications of the 7806 IC. Input Voltage range: 8V to 25V Output Voltage: 5.75V(min) – 6.25V(max) Output Current: 1A Peak current: 2.2A Operating Temperature : 0 to 125 C Polarity: Positive Note: More technical information can be found in the LM7806 Datasheet, linked at the bottom of this page. LM7806 Pinout Configuration The IC comes in compact packaging with 3 pins for input/output and ground pins. The table below can be referred to understand the pin configuration of the IC. Pin Number Pin Type Pin Description 1 IN Positive Input Voltage 2 GND Ground 3 OUT Positive Output Voltage
