Description Bruker TRACER 5i Handheld XRF Spectrometer The Bruker TRACER 5i Handheld XRF Spectrometer is a portable device designed for precise elemental analysis in both field and laboratory settings. Capable of detecting elements from Sodium (Na) to Uranium (U), the TRACER 5i excels in methods development, research, and complex material analysis. Advanced Technology for Material Applications Key Features of TRACER 5i 8 μm Beryllium Detector Window: Ensures sensitivity to light elements. SharpBeam™ Geometry: Maximizes count rate, improves light element sensitivity, and minimizes X-ray scatter. Integrated Camera: Internal VGA CCD camera with adjustable lighting, capable of storing up to 5 photos per assay. Connectivity: Bluetooth, Wi-Fi, and USB for seamless data transfer and remote operation. Measurement Atmospheres: Operates in air, helium, or vacuum environments for diverse applications. Software Support ARTAX™ Software: Advanced XRF spectral analysis. EasyCal™ Software: For user-created single-phase calibrations. Applications of Bruker TRACER 5i Art Conservation and Authentication Evaluate pigments and objects for authentication and conservation. Determine authenticity, fabrication details, and identify non-original materials. Exploratory Geology Analyze geochemistry, including ores, drill cuttings, soil, and sediment. Archaeological Studies Source obsidian, lithic, and ceramics. Assess authenticity and ensure proper conservation. Food Safety Quality analysis of raw or finished products. Hazardous analysis and foreign body identification. Plant and Soil Health Analyze fertilizers, nutrients, and heavy metals. Material Science and Research Support research across disciplines like chemistry, physics, and geology. Bruker TRACER 5i Handheld XRF Spectrometer Key Specifications Feature Details Detector Proprietary 20 mm² silicon drift detector Detector Window 8 μm Beryllium Dimensions 27.3 cm x 9.4 cm x 29.5 cm (10.75 in x 3.7 in x 11.6 in) Weight 1.9 kg (4.1 lbs) with battery Power Li-Ion battery and charger; AC adapter Excitation Source Rhodium thin-window X-ray tube Collimation User-changeable (3 mm and 8 mm collimators) Filters Five-position motorized filter wheel Beam Path Air, vacuum, helium Internal Camera VGA CMOS camera with 5-photo storage per assay Display 9.4 cm (3.7 in) daylight-visible color touchscreen Connectivity USB, Wi-Fi, Bluetooth Operating Environment -10°C to 50°C (14°F to 122°F), IP54 rated Bruker TRACER 5i Handheld XRF Spectrometer Included in the Package Bruker TRACER 5i Handheld XRF Analyzer. Manual filter kit with filter holders and tools. Internal VGA CCD camera with adjustable lighting. Wi-Fi, Bluetooth connectivity, USB port, and portable router. EasyAccess™ rail mount for accessories. Relaxed Grip Strap™ for comfortable handling. ARTAX™ and EasyCal™ software for advanced spectral analysis. Two high-performance Li-Ion batteries with charger. Custom carry-on shipping case with foam inserts and wheels. 1-year warranty. The Bruker TRACER 5i Handheld XRF Spectrometer is the ultimate solution for professionals requiring accurate, portable elemental analysis across diverse applications.
